ALCF Inference Endpoints

Unlock Powerful AI Inference at Argonne Leadership Computing Facility (ALCF). This service provides API access to a variety of state-of-the-art open-source models running on dedicated ALCF hardware.

Quick Start

This guide will walk you through the fastest ways to start using the ALCF Inference Endpoints.

Web UI

The easiest way to get started is through the web interface, accessible at https://inference.alcf.anl.gov/

The UI is based on the popular Open WebUI platform. After logging in with your ANL or ALCF credentials, you can:

  1. Select a model from the dropdown menu at the top of the screen.
  2. Start a conversation directly in the chat interface.

In the model selection dropdown, you can see the status of each model:

Inference Endpoints Web UI

  • Live: These models are "hot" and ready for immediate use.
  • Starting: A node has been acquired and the model is being loaded into memory.
  • Queued: The model is in a queue waiting for resources to become available.
  • Offline: The model is available but not currently loaded. It will be queued for loading when a user sends a request.
  • All: Lists all available models regardless of their status.

For Advanced UI Features

For a full guide on advanced features like RAG (Retrieval-Augmented Generation), function calling, and more, please refer to the official Open WebUI documentation.

API Access

For programmatic access, you can use the API endpoints directly.

1. Setup Your Environment

You can run the following setup from anywhere (your local machine, or an ALCF machine).

# Create a new Conda environment
conda create -n globus_env python==3.11.9 --y
conda activate globus_env

# Install necessary packages
pip install openai globus_sdk

2. Authenticate

To access the endpoints, you need an authentication token.

# Download the authentication helper script
wget https://raw.githubusercontent.com/argonne-lcf/inference-endpoints/refs/heads/main/inference_auth_token.py

# Authenticate with your Globus account
python inference_auth_token.py authenticate

This will generate and store access and refresh tokens in your home directory.

Token Validity

  • Access tokens are valid for 48 hours. The get_access_token command will automatically refresh your token if it has expired.
  • An internal policy requires re-authentication every 7 days. If you encounter permission errors, logout from Globus at app.globus.org/logout and re-run python inference_auth_token.py authenticate --force.

3. Make a Test Call

Once authenticated, you can make a test call using cURL or Python.

#!/bin/bash

# Get your access token
access_token=$(python inference_auth_token.py get_access_token)

curl -X POST "https://inference-api.alcf.anl.gov/resource_server/sophia/vllm/v1/chat/completions" \
     -H "Authorization: Bearer ${access_token}" \
     -H "Content-Type: application/json" \
     -d '{
            "model": "meta-llama/Meta-Llama-3.1-8B-Instruct",
            "messages":[{"role": "user", "content": "Explain quantum computing in simple terms."}]
         }'

from openai import OpenAI
from inference_auth_token import get_access_token

# Get your access token
access_token = get_access_token()

client = OpenAI(
    api_key=access_token,
    base_url="https://inference-api.alcf.anl.gov/resource_server/sophia/vllm/v1"
)

response = client.chat.completions.create(
    model="meta-llama/Meta-Llama-3.1-8B-Instruct",
    messages=[{"role": "user", "content": "Explain quantum computing in simple terms."}]
)

print(response.choices[0].message.content)

API Usage Examples

Querying Endpoint Status

Querying Endpoint Status

You can check the status of models on the cluster and list all available endpoints programmatically.

This endpoint provides information about what is currently live or queued.

#!/bin/bash

# Get your access token
access_token=$(python inference_auth_token.py get_access_token)

curl -X GET "https://inference-api.alcf.anl.gov/resource_server/sophia/jobs" \
 -H "Authorization: Bearer ${access_token}"

This provides a list of all available endpoints.

#!/bin/bash

# Get your access token
access_token=$(python inference_auth_token.py get_access_token)

curl -X GET "https://inference-api.alcf.anl.gov/resource_server/list-endpoints" \
 -H "Authorization: Bearer ${access_token}"

Chat Completions

Chat Completions

This endpoint is used for conversational AI.

#!/bin/bash
access_token=$(python inference_auth_token.py get_access_token)
curl -X POST "https://inference-api.alcf.anl.gov/resource_server/sophia/vllm/v1/chat/completions" \
     -H "Authorization: Bearer ${access_token}" \
     -H "Content-Type: application/json" \
     -d '{
            "model": "meta-llama/Meta-Llama-3.1-8B-Instruct",
            "temperature": 0.2,
            "max_tokens": 150,
            "messages":[{"role": "user", "content": "What are the symptoms of diabetes?"}]
         }'

from openai import OpenAI
from inference_auth_token import get_access_token

access_token = get_access_token()
client = OpenAI(
    api_key=access_token,
    base_url="https://inference-api.alcf.anl.gov/resource_server/sophia/vllm/v1"
)

response = client.chat.completions.create(
    model="meta-llama/Meta-Llama-3.1-8B-Instruct",
    messages=[{"role": "user", "content": "What are the symptoms of diabetes?"}]
)
print(response.choices[0].message.content)

Vision Language Models

Vision Language Models

Use this endpoint to analyze images with text prompts.

from openai import OpenAI
import base64
from inference_auth_token import get_access_token

access_token = get_access_token()
client = OpenAI(
    api_key=access_token,
    base_url="https://inference-api.alcf.anl.gov/resource_server/sophia/vllm/v1"
)

def encode_image(image_path):
    with open(image_path, "rb") as image_file:
        return base64.b64encode(image_file.read()).decode('utf-8')

image_path = "scientific_diagram.png" # Replace with your image
base64_image = encode_image(image_path)

response = client.chat.completions.create(
    model="Qwen/Qwen2-VL-72B-Instruct",
    messages=[
        {
            "role": "user",
            "content": [
                {"type": "text", "text": "Describe the key components in this scientific diagram"},
            ]
        }
    ],
    max_tokens=300
)
print(response.choices[0].message.content)

Embeddings

Embeddings

This endpoint generates vector embeddings from text, currently supported by the infinity framework.

from openai import OpenAI
from inference_auth_token import get_access_token

access_token = get_access_token()
client = OpenAI(
    api_key=access_token,
    base_url="https://inference-api.alcf.anl.gov/resource_server/sophia/vllm/v1"
)

response = client.embeddings.create(
  model="mistralai/Mistral-7B-Instruct-v0.3-embed",
  input="The food was delicious and the waiter...",
  encoding_format="float"
)
print(response.data[0].embedding)

For more examples, please see the inference-endpoints GitHub repository.

Available Models

Click to see the list of available models

Models are marked with the following capabilities:

  • B - Batch Enabled
  • T - Tool Calling Enabled
  • R - Reasoning Enabled

Chat Language Models

Qwen Family

  • Qwen/Qwen2.5-14B-InstructBT
  • Qwen/Qwen2.5-7B-InstructBT
  • Qwen/QwQ-32BBRT
  • Qwen/Qwen3-235B-A22BRT
  • Qwen/Qwen3-32BBR

Meta Llama Family

  • meta-llama/Meta-Llama-3-70B-InstructB
  • meta-llama/Meta-Llama-3-8B-InstructB
  • meta-llama/Meta-Llama-3.1-70B-InstructBT
  • meta-llama/Meta-Llama-3.1-8B-InstructBT
  • meta-llama/Meta-Llama-3.1-405B-InstructBT
  • meta-llama/Llama-3.3-70B-InstructBT
  • meta-llama/Llama-4-Scout-17B-16E-InstructBT
  • meta-llama/Llama-4-Maverick-17B-128E-InstructT

Mistral Family

  • mistralai/Mistral-7B-Instruct-v0.3B
  • mistralai/Mistral-Large-Instruct-2407B
  • mistralai/Mixtral-8x22B-Instruct-v0.1B

Nvidia Nemotron Family

  • mgoin/Nemotron-4-340B-Instruct-hf

Aurora GPT Family

  • argonne-private/AuroraGPT-IT-v4-0125B
  • argonne-private/AuroraGPT-Tulu3-SFT-0125B
  • argonne-private/AuroraGPT-DPO-UFB-0225B
  • argonne-private/AuroraGPT-7B-OIB

Allenai Family

  • allenai/Llama-3.1-Tulu-3-405B

OpenAI Family

  • openai/gpt-oss-20bBR
  • openai/gpt-oss-120bBR

Google Family

  • google/gemma-3-27b-itBT

Vision Language Models

Qwen Family

  • Qwen/Qwen2-VL-72B-InstructB

Meta Llama Family

  • meta-llama/Llama-3.2-90B-Vision-Instruct

Embedding Models

Mistral Family

  • mistralai/Mistral-7B-Instruct-v0.3-embedB
  • Salesforce/SFR-Embedding-MistralB

Nvidia Family

  • nvidia/NV-Embed-v2

Want to add a model?

To request a new model, please contact ALCF Support.

Batch Processing

For large-scale inference, the batch processing service allows you to submit a file with up to 150,000 requests.

Batch Processing Requirements

  • You must have an active ALCF allocation.
  • Input files and output folders must be located within the /eagle/argonne_tpc project space or a world-readable directory.
  • Each line in the input file must be a complete JSON request object (JSON Lines format).
  • Only models marked with B support batch processing.

Batch API Endpoints

Create Batch

Create Batch Request
#!/bin/bash

# Get your access token
access_token=$(python inference_auth_token.py get_access_token)

# Define the base URL
base_url="https://inference-api.alcf.anl.gov/resource_server/sophia/vllm/v1/batches"

# Submit batch request
curl -X POST "$base_url" \
     -H "Authorization: Bearer ${access_token}" \
     -H "Content-Type: application/json" \
     -d '{
          "model": "meta-llama/Meta-Llama-3.1-8B-Instruct",
          "input_file": "/eagle/argonne_tpc/path/to/your/input.jsonl"
        }'

# Submit batch request with custom output folder
curl -X POST "$base_url" \
     -H "Authorization: Bearer ${access_token}" \
     -H "Content-Type: application/json" \
     -d '{
          "model": "meta-llama/Meta-Llama-3.1-8B-Instruct",
          "input_file": "/eagle/argonne_tpc/path/to/your/input.jsonl",
          "output_folder_path": "/eagle/argonne_tpc/path/to/your/output/folder/"
        }'

import requests
import json
from inference_auth_token import get_access_token

# Get your access token
access_token = get_access_token()

# Define headers and URL
headers = {
    'Authorization': f'Bearer {access_token}',
    'Content-Type': 'application/json'
}
url = "https://inference-api.alcf.anl.gov/resource_server/sophia/vllm/v1/batches"

# Submit batch request
data = {
    "model": "meta-llama/Meta-Llama-3.1-8B-Instruct",
    "input_file": "/eagle/argonne_tpc/path/to/your/input.jsonl",
    "output_folder_path": "/eagle/argonne_tpc/path/to/your/output/folder/"
}

response = requests.post(url, headers=headers, json=data)
print(response.json())

Retrieve Batch

Retrieve Batch Metrics
#!/bin/bash

# Get your access token
access_token=$(python inference_auth_token.py get_access_token)

# Get results of specific batch
batch_id="your-batch-id"
curl -X GET "https://inference-api.alcf.anl.gov/resource_server/v1/batches/${batch_id}/result" \
     -H "Authorization: Bearer ${access_token}"

import requests
from inference_auth_token import get_access_token

# Get your access token
access_token = get_access_token()

# Define headers and URL
headers = {
    'Authorization': f'Bearer {access_token}'
}
batch_id = "your-batch-id"
url = f"https://inference-api.alcf.anl.gov/resource_server/v1/batches/{batch_id}/result"

# Get batch results
response = requests.get(url, headers=headers)
print(response.json())

Sample Output:

{
    "results_file": "/eagle/argonne_tpc/path/to/your/output/folder/<input-file-name>_<model>_<batch-id>/<input-file-name>_<timestamp>.results.jsonl",
    "progress_file": "/eagle/argonne_tpc/path/to/your/output/folder/<input-file-name>_<model>_<batch-id>/<input-file-name>_<timestamp>.progress.json",
    "metrics": {
        "response_time": 27837.440138816833,
        "throughput_tokens_per_second": 3899.833442250346,
        "total_tokens": 108561380,
        "num_responses": 99985,
        "lines_processed": 100000
    }
}

List Batch

List All Batches
#!/bin/bash

# Get your access token
access_token=$(python inference_auth_token.py get_access_token)

# List all batches
curl -X GET "https://inference-api.alcf.anl.gov/resource_server/v1/batches" \
     -H "Authorization: Bearer ${access_token}"

# Optionally filter by status (pending, running, completed, or failed)
curl -X GET "https://inference-api.alcf.anl.gov/resource_server/v1/batches?status=completed" \
     -H "Authorization: Bearer ${access_token}"

import requests
from inference_auth_token import get_access_token

# Get your access token
access_token = get_access_token()

# Define headers and URL
headers = {
    'Authorization': f'Bearer {access_token}'
}
url = "https://inference-api.alcf.anl.gov/resource_server/v1/batches"

# List all batches
response = requests.get(url, headers=headers)
print(response.json())

# Optionally filter by status (pending, running, completed, or failed)
params = {'status': 'completed'}
response = requests.get(url, headers=headers, params=params)
print(response.json())

Sample Output:

[
  {
    "batch_id": "f8fa8efd-1111-476d-a0a0-111111111111",
    "cluster": "sophia",
    "created_at": "2025-02-20 18:39:58.049584+00:00",
    "framework": "vllm",
    "input_file": "/eagle/argonne_tpc/path/to/your/output/folder/chunk_a.jsonl",
    "status": "pending"
  },
  {
    "batch_id": "4b8a31b8-2222-479f-8c8c-222222222222",
    "cluster": "sophia",
    "created_at": "2025-02-20 18:40:30.882414+00:00",
    "framework": "vllm",
    "input_file": "/eagle/argonne_tpc/path/to/your/output/folder/chunk_b.jsonl",
    "status": "pending"
  }
]

Batch Status

Get Batch Status
#!/bin/bash

# Get your access token
access_token=$(python inference_auth_token.py get_access_token)

# Get status of specific batch
batch_id="your-batch-id"
curl -X GET "https://inference-api.alcf.anl.gov/resource_server/v1/batches/${batch_id}" \
     -H "Authorization: Bearer ${access_token}"

import requests
from inference_auth_token import get_access_token

# Get your access token
access_token = get_access_token()

# Define headers and URL
headers = {
    'Authorization': f'Bearer {access_token}'
}
batch_id = "your-batch-id"
url = f"https://inference-api.alcf.anl.gov/resource_server/v1/batches/{batch_id}"

# Get batch status
response = requests.get(url, headers=headers)
print(response.json())

Batch Status Codes: - pending: The request was submitted, but the job has not started yet. - running: The job is currently running on a compute node. - failed: An error occurred; the error message will be displayed when querying the result. - completed: :tada:

Cancel Batch

Cancel Submitted Batch

The inference team is currently developing a mechanism for users to cancel submitted batches. In the meantime, please contact us with your batch_id if you have a batch to cancel.

System Details

Available Clusters

Cluster Status Endpoint Notes
Sophia Active https://inference-api.alcf.anl.gov/resource_server/sophia 8 nodes reserved for Inference
SambaNova SN40L (Metis) Coming Soon https://inference-api.alcf.anl.gov/resource_server/metis
Cerebras CS-3 Inference cluster Coming Soon
GH200 Nvidia Cluster Coming Soon

Endpoints and Frameworks

  • vLLM: https://inference-api.alcf.anl.gov/resource_server/sophia/vllm
  • Infinity: https://inference-api.alcf.anl.gov/resource_server/sophia/infinity

The primary API endpoints follow the OpenAI standard: - /v1/chat/completions - /v1/completions - /v1/embeddings - /v1/batches

Performance and Wait Times

  • Cold Starts: The first query to an inactive model may take 10-15 minutes to load.
  • Queueing: During high demand, your request may be queued until resources are available.
  • Payload Limits: Payloads are limited to 10MB. Use batch mode for larger inputs.

On Sophia, from the 8 nodes reserved for inference, 5 nodes are dedicated to serving popular models "hot" for immediate access. The remaining 3 nodes rotate through other models based on user requests. These dynamically loaded models will remain active for up to 24 hours.

Important Notes

  • The default response format for the API is text/plain.
  • The Globus backend does not support streaming. Please ensure stream: False is set when integrating with RAG applications.
  • If you’re interested in extended model runtimes, reservations, or private model deployments, please contact ALCF Support.

Troubleshooting

  • Connection Timeout: The model you are requesting may be queued as the cluster has too many pending jobs. You can check model status by querying the /jobs endpoint. See Querying Endpoint Status for an example.
  • Permission Denied: Your token may have expired. Logout from Globus at app.globus.org/logout and re-authenticate using the --force flag.
  • Batch Permission Error: Ensure your input/output paths are in a readable location like /eagle/argonne_tpc.

Contact Us

For questions or support, please contact ALCF Support.
